WAFER MDB-RS232 - Coin Dispensing Data; Coin Dispensed Data; MDB Status Codes

MDB-RS232 Interface Adapter for MDB Coin Changer Bill Acceptor and MDB card reader
Page 8 of 12 http://www.waferlife.com
NICKEL
08 50 00
08 50 06
08 40 4C
DIME
08 51 00
08 51 08
08 41 6B
QUARTER
08 52 00
08 52 06
08 42 4B
QUARTER (1)
08 52 00
08 52 06
08 42 15
$1 CANADIAN*
08 44 00
$2 CANADIAN*
08 45 00
* Dollar coins are routed directly to the cash box
Coin Dispensed Manually
NICKEL
08 90 00
08 90 06
08 90 4C
DIME
08 91 00
08 91 08
08 91 6B
QUARTER
08 92 00
08 92 06
08 92 4B
QUARTER (1)
08 92 00
08 92 06
08 92 15
Coin Rejected
NICKEL
08 70 00
08 70 06
08 70 4C
DIME
08 71 00
08 71 08
08 71 6B
QUARTER
08 72 00
08 72 06
08 72 4B
QUARTER (1)
08 72 00
08 72 06
08 72 15
$1 CANADIAN*
08 74 00
$2 CANADIAN*
08 75 00
MDB STATUS
01
Escrow Request
02
Changer Payout Busy
03
No Credit
04
Defective Tube Sensor
05
Double Arrival
06
Acceptor Unplugged
07
Tube Jam
08
ROM Checksum Error
09
Coin Routing Error
0A
Changer Busy
0B
Changer was Reset
0C
Coin Jam
21
Coin not recognized/slug. Returned
Upon startup one of these values below may be sent to the PC – These are the VMC
Commands.
08
Reset
09
Status
0A
Tube Status
0B
Poll
0C
Coin Type
0D
Dispense
