WAGO 750-461 Series User Manual

58 Appendix WAGO-I/O-SYSTEM 750
750-461 2AI Pt100/RTD
Manual
Version 1.4.1
Table 41: Specific Module / Channel Parameters for 75x-652
GSD File
WAGO-I/O-CHECK
Description
Value
Selection box
Value
Baud rate
[Baud]
300
Transmission Rate
[Baud]
300
1200
Transmission Rate
[Baud]
1200
2400
Transmission Rate
[Baud]
2400
4800
Transmission Rate
[Baud]
4800
9600
*)
Transmission Rate
[Baud]
9600
19200
Transmission Rate
[Baud]
19200
38400
Transmission Rate
[Baud]
38400
57600
Transmission Rate
[Baud]
57600
115200
Transmission Rate
[Baud]
115200
600
Transmission Rate
[Baud]
600
Data bits
8
*)
Data Bits
8
*)
7
Data Bits
7
Parity
None
*)
Parity
None
*)
Odd
Parity
Odd
Straight
Parity
Straight
Stop bits
1
*)
Stop Bits
1
*)
2
Stop Bits
2
Flow control
Deactivated
*)
Flow Control
Disabled
*)
XON/XOFF
Flow Control
XON/XOFF
RTS/CTS
Flow Control
RTS/CTS
RTS, lead/follow-on time
Flow Control
RTS, lead/follow-on
time
Continuous
send
Lock
*)
Continuous Send Mode
Disabled
*)
Release
Continuous Send Mode
Release
Continuous
receive
Lock
*)
Continuous Receive Mode
Disabled
*)
Release
Continuous Receive Mode
Release
Switching time
RS-485
100 µs
*)
Switchover Time RS-485
100 µs
*)
2 characters
Switchover Time RS-485
2 Characters
4 characters
Switchover Time RS-485
4 Characters
Monitoring
time con.
receive
2 characters
*)
Continuous Receive
Tiemout
2 Characters
*)
4 characters
Continuous Receive
Timeout
4 Characters
*)
Default setting
con. = continuous
