LED Indication Example
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
For every LED there is one definition for red and one for green. Each of the
three LEDs can be regarded as two separate LEDs. If, for example, the user
LED is switched to RED (on) and at the same time switched to GREEN (on),
it lights orange-green. The combination RED (on) and GREEN-BLINKING is
also possible and results in a user LED that blinks rot, orange-green.
The header file also contains the ledman_cmd macro which imlements the
access to the kernel driver. Every time the driver is called, /dev/ledman is
opened, written to and closed again.
Source code description: leds.c
The leds.c file contains the main() function. The console entries are analyzed
and the ledman_cmd() macro (which is defined in leds.h) with its parameter
values is called. The help text for the option "-help" is also defined here.

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
