WAGO I/O SYSTEM 750 XTR Commissioning 175
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
7.8.1.34 “Configuration of SNMP v1/v2c Parameters” Page
The general settings for SNMP v1/v2c are shown on the “Configuration of SNMP
v1/v2c Parameters” page.
7.8.1.34.1 “SNMP v1/v2c Manager Configuration” Group
Table 110: WBM “Configuration of SNMP v1/v2c Parameters” Page – “SNMP v1/v2c Manager
Configuration” Group
Protocol enabled
It is displayed the SNMP protocol for v1/v2c is
activated. The local community name is deleted
when the protocol is deactivated.
Local Community Name
Specify here the community name for the SNMP
manager configuration. The community name can
establish relationships between SNMP managers
and agents who are respectively referred to as
“Community” and who control identification and
access between SNMP participants.
The community name can be up to 32 characters
long and must not include spaces.
To use the SNMP protocol, a valid community name
must always be specified. The default community
Click [Change] to apply changes. The changes only take effect after restarting
the controller. For this purpose, use the WBM reboot function. Do not shut down
the controller too early!
7.8.1.34.2 “Actually Configured Trap Receivers” Group(s)
Table 111: WBM “Configuration of SNMP v1/v2c Parameters” Page – “Actually Configured Trap
Receivers” Group
This displays number of configured trap receivers.
