QUICK-START
Preparaon
1. Lay the detector
Put the detector on a wooden or plastic table, and let the search coil stretch
out of the table above 30cm, Keep away from walls, ceilings and oors,
turn off all kinds of electrical appliances that will cause electromagnetic
interference, remove watches and rings from hands.
2. Turn on
• Press the POWER button, the detector will sound two moo tones, and all
LCD patterns will be lit for a moment. And the detector is set by default
last shutdown.
3. ALL METAL mode test
Press the MODE button, the A-M cursor will light. Sweep six sample metals
(iron nail, nickel coin, pull-tab, Zinc coin, copper coin and silver coin) above
the search coil 7-10cm respectively.
a. The detector sounds three different tones in turn.
b. The depth cursor indicates the second grade.
c. The target cursor ashes respectively. The digital cursor shows the
corresponding number.
