1: LCD DISPLAY
2: Slider (49/61 only)
3: Encoders
4: Transport buttons
5: Assignable buttons (49/61 only)
6: Trigger Pads
7: Function buttons
8: Numeric keypad
9: Pitch Bend wheel
10: Modulation wheel
11: Keyboard with Aftertouch
12: Pedal A
13: Pedal B
14: MIDI OUT port
15: MIDI IN port
16: USB 2.0 port
17: DC power socket
18: Power switch
1. Display LCD
2. Slider-deslizante (somente no 49/61)
3. Encoders
4. Botões de Transposição
5. Botão Endereçável (somente no 49/61)
6. Pads Dispadores
7. Botões de Função
8. Teclado Numérico
9. Roda Pitch Bend
10. Roda Modulation
11. Teclado com Aftertouch
12. Pedal A
13. Pedal B
14. Porta MIDI OUT
15. Porta MIDI IN
16. Porta USB 2.0
17. Soquete DC Power
18. Chave Power
Controls and Connections / Controles e Conexões
