16
Controls
231776 Element Assembly 10.5kW (PC8140E).
232605 Element Assembly 7.0kW (PC8140E-7).
232744 Element Retaining Pin.
232750 Element ‘O’ Ring.
232746 Bulkhead ‘O’ Ring.
232740 Overtemp Thermostat (Reset Switch).
232741 Thermostat.
015561 Thermostat Knob.
235403 Water Valve.
232733 Control Panel.
227962 Neon Green.
227963 Neon Orange.
232736 Element Control Switch.
227401 Element Control Knob.
232775 Terminal Block.
231738 Contactor.
232748 Microswitch.
General
229682 Basket Support Frame.
238674 Pasta Basket LH 1/6 165 x 125mm.
238819 Pasta Basket RH 1/6 165 x 125mm.
227856 Door Magnet.
233698 Water Filler Spout.
019390 Water Drain Valve.
229823 Overflow Hose.
229822 Drain ‘Y’ Junction.
228933 Basin Connector.
227850 Adjustable Leg - 150mm.
Accessories (Optional)
228793 Plinth Kit.
229836 Pasta Cooker Basket 1/4 165 x 165mm.
229837 Pasta Cooker Basket 1/2 320 x 165mm.
240542 Noodle Kit (Electric) - includes 5 x Noodle Baskets + Noodle Basket Tray.
Replacement Parts List
When ordering spare parts, please quote the part number and the description as listed below. If the part
required is not listed below, request the part by description and quote model number and serial number
which is shown on the rating plate.
IMPORTANT:
Only genuine authorized replacement parts should be used for the servicing and repair
of this appliance. The instructions supplied with the parts should be followed when
replacing components.
For further information and servicing instructions, contact your nearest authorized
service branch (contact details are as shown on the reverse of the front cover of this
manual).
