Walker Bay 8 - Page 13

!
1
2
23.75"
60.5cm
Push nut in completely
before tightening to avoid
stripping nut housing.
5
4a
4b
3
6
1/4"— 20 X 1-1/2" X (8)
7
A
A
A
1/4"— 20 X 1-1/4" X (12)
Nut Driver
#14 x 3/4" X (2)
1
5
2 3 4
7
Keel Plate
Foam Plug
Bow Eye
Bow and Stern Seats
(2) X
#10 X 3/4"
X (4)
X (2)
Oarlock Sockets
and Oarlocks
Mid-seat
A
a
b
X (2)
8
WB8 Basic Assembly Instructions
WB8 Classic See atachment: Classic Assembly Instructions
WB9 RID See atachment: WB9 RID Assembly Instructions
1/4"— 20 X 1-1/4"
X (12)
1/4"— 20 X 1-1/4" X (4)
6
Motor Mounting Plates
8
Oars, Blades
and Collars
8
Assembly – WB8 Montage – WB8 WB8 – Montage WB8 – Montaje Montaggio – WB8 Montage – WB8 WB8 – Aggregat
13/14 (blank)
