Operating Instructions
29
Operating Controls (T
op View from Drivers Point of V
iew)
1.
2.
BLADE
CLUTCH
(PTO)
Pull Up to Engage
P
ARKING
BRAKE
THROTTLE
The Forward Speed Control also Establishes the
Neutral-Park
Position of the Steering Levers
Forward Position
(No Control Change)
LEFT WHEEL
STEERING LEVER
Reverse Drive
Wheel Motion
Position
Neutral-Park
Position
RIGHT WHEEL
STEERING LEVER
Fast
Throttle
Position
Idle
Position
Engaged
Position
Disengaged
Position
Disengaged
Position
Engaged
Position
Neutral-Park
Position
Full Forward
Ground Speed
Position
Intermediate
Ground Speed
Position
FORW
ARD SPEED
CONTROL
LEVER (FSC)
32
34
