5. Streaking- uneven spray pattern Remove as in 2 and clean or replace
Material buildup on nozzle.
Clean nozzle cut out, with stiff card. Preferably
wash. Soak overnight in “Milton” sterilising
solution.
Nozzle incorrectly aligned.
Release nozzle cap by turning the cap one half
turn anti-clockwise, realign nozzle and
retighten the cap.
Mixed nozzles.
You may have different nozzles fitted.
Refit matching nozzles as required.
Machines fitted with an on / off tap.
6. Machine still sprays when the tap is turned off. The return tube to the tank is blocked.
Remove and flush with garden hose to clear
blockage.
If the unit is being towed, the towing speed is
too fast.
