Item Number Quantity Part Number Description
1 1 W1106 Main Frame
2 1 W1619 Handle L/H
3 1 W1633 Handle R/H
4 6 W1130 M6 x 35 Hex Head Set Screw
5 10 W1036 M6 Plain Washer
6 6 W1041 M6 Nut
7 1 W1108 Plate - Pump
8 4 W1068 M4 Spring Washer
9 4 W1043 M4 Nut
10 2 W1113 Dowel Pin
11 1 W1345 12” Pneumatic Wheel PW400-4-4/11
12 2 W1028 Dowel Pin
13 2 W1112 Bush
14 2 W1110 Bush
15 2 W1111 Drive Coupling
16 2 W1033 ⅜” Spring Dome Nut
17 1 W1109 Axle
18 1 W1132 Circlip
19 1 W1353 Washer - Pump Spacer
20 1 W1571 Hose Shank Connector NYB 8400-406
21 1 W1570 Wing Nut CP1803A – NYB
22 1 W1569 Inlet Connector ½ ” Pipe QJ7421 – ½” - NYB
23 2 W1572 End Plug
24 2 W1566 Split Eyelet DCV for ½” Tube QJ17560- 1 ½” NYB
25 2 W1568 Seal CB19438 EPR
26 2 W1574 2.0 TF VP Nozzle – Red
27 2 W1581 Nozzle Cap CP25599 – 1 NYB
28 2 W1575 3.0 TF VP Nozzle – Grey
29 1 W1116 ½” Bridge Clamp
30 1 W1117 ½” Rectangular Clamp
31 1 W1573 ½” ID x 22” Long Durapipe PP ½” Class ‘E’47335
32 1 W2057 Pump Hex Drive
33 1 W1069 Outlet Securing Clip
34 1 W1279 ½” BSP Cap and Liner
35 1 W1276 Elbow & Nut 11/16” NPT x ⅜” Hose Tail
36 1 W1415 ⅜” ID x ⅛” x 27” Long Tube (Tap to Tank)
37 1 W1166 ¼” BSP x ⅜” Hose Tail Elbow
38 1 W1628 ¼” BSP Ball Valve
39 1 W1121 ¼” BSP x ⅜” Hose Tail
40 1 W1414 ⅜” ID x ⅛” x 24” Long Tube (Tap to Tee)
41 1 W1125 ⅜” Equal Tee
42 1 W1413 ⅜” ID x ⅛” x 18” Long Tube (Tee to Boom Inlet)
43 1 W1122 Taper Sleeve
44 4 W1096 Stepless Clamp 22.6
45 2 W1006 Elbow
46 2 W1004 Elbow ‘O’ Ring
47 1 W1667 5/8” ID x ⅛” x 8 ½” Long Tube (Pump to Elbow)
48 7 W1223 Stepless Clamp 18.5
49 1 W1126 Tank Only
50 1 W1046 Filter
51 1 W1590 Decal
52 1 W1139 Content Label (not shown)
53 1 W2071 Tank Assembly (Includes items
35,44,47,49,51,52,56,57,58,59,60,61)
54 1 W1134 Handle Grip – Black
55 1 W1629 Extension Tube ¼” Female/Female
56 - - Not Used
57 1 W1635 ½” BSP Tank Connector – 8050151
58 1 W1636 ½” BSP Back Nut – 8042151
59 1 W1637 Gasket Washer – G00002008
60 1 W1666 ⅝” ID x ⅛” x 3 ½” Long Tube (Elbow to Tank)
RAMBLER PARTS LIST:
