WARNING
The system must not be energized unless the system is
installed according to the instructions and the installation
meets all applicable codes. Warranty is void if not
installed according to this instruction manual and proper
procedure.
CAUTION
Disconnect all electrical power prior to installing or
servicing this unit.
ERROR DETECTION
The MTC-1991-WU has built-in error detection which will
de-energize the heating circuit if the sensor is damaged or
if it detects an open or shorted sensor circuit.
TECHNICAL DATA
Power supply: 230-240V AC ±10%, 50Hz
Output relay, SPST
(resistive load): 16A
Built-in switch: 2 pole, 16A
Ambient operating temperature: 0-50⁰C
Scale limitation: minimum and maximum
Scale range: 10-50⁰C
Temperature setback: not available
On/Off differential: 0.4⁰C
Enclosure: IP20
Dimensions: 115mm(h) x 84mm(w) x 50mm(d)
TWELVE (12) MONTH WARRANTY
This product is warranted against defects in material and workmanship under normal conditions of use for a period of
twelve months from the date of purchase. During this period, Warmtech will repair or replace the product, if it is defective
in normal operating conditions in terms of materials or workmanship, with a new product of equivalent quality at Warmtech’s
option. The warranty does not cover costs of transportation, removal, installation or damage caused by misuse or accident.
In no event will Warmtech be liable for consequential loss resulting from the installation of the product. Any defective
product should be sent with the original invoice to the original installer, or shipped prepaid, insured and sent to Warmtech.
CUSTOMER ASSISTANCE
Phone: 1300 138 126
Email: info@warmtech.com.au
Website: www.warmtech.com.au
Warranty
FIGURE 1 FIGURE 2
WITH FLOOR SESNOR
