Warn 102770 - Safety Caution - Moving Parts Entanglement Hazard; Notice - Equipment Damage; Tools and Parts Required

©2018 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 2 64673A2
NOTICE
Equipment Damage
• Always refer to the Installation and Specication Guide, supplied in the winch kit, for all wiring schematics and specic details on how to wire this WARN product to your vehicle.
• Always put the end of the actuator cable through the slot in the Termination Bracket. Terminating the cable through any other hole in the bracket will cause the bracket to not function properly and will drastically reduce
the life of the actuator cable.
Read installation and operating instructions thoroughly.
CAUTION
Moving Parts Entanglement Hazard
FAILURE TO OBSERVE THESE INSTRUCTIONS COULD LEAD TO MINOR OR MODERATE INJURY
• Always take time to fully read and understand the installation and Operations Guide included with this product.
• Never operate this product if you are under 16 years of age.
• Never operate this product when under the inuence of drugs, alcohol or medications.
Read installation and operating instructions thoroughly.
TABLE OF CONTENTS
Tools Required ............................................................................................................................. page 2
Parts List.........................................................................................................................................page 2
Torque Specications ................................................................................................................page 2
Installation ................................................................................................................................page 3-4
Maintenance/Care ......................................................................................................................page 4
TOOLS REQUIRED
- Rachet
- 7/16” Socket
- 7/16” Box Wrench
- 1/2” Socket or Box Wrench
- 9/16” Socket
- 9/16” Box Wrench
- Drill
- 3/8” Drill Bit
- Diagonal Cutter or Similar
- Permanent Marker or Similar
PARTS LIST
Ref PN Description
Qty
A1 64224 Plow Mount
1
A2 64227 Tab
1
A3 62845 J-Bolt Bracket
1
B1 31804 1/4” dia-1” long Bolt
2
B2 35391 1/4” J-bolt
2
B3 1320 1/4” Washer
2
B4 6725 1/4” Nylock Nut
4
C1 60869 5/16” dia-1 3/8” wide U-bolt
4
C2 1324 5/16” Washer
8
C3 2002 5/16” Nylock Nut
8
D1 1827 3/8” dia-1” long Bolt
1
D2 6779 3/8” Nylock Nut
1
TORQUE SPECIFICATIONS
Please use the recommended torque specications when
assembling this product unless otherwise specied in the
instructions.
FASTENER SIZE FASTENER TORQUE
lb-ft (N.m)
1/4" 8 (11)
5/16" 17 (23)
3/8" 30 (40)
7/16” 48 (66)
1/2" 74 (100)
9/16” 106 (144)
5/8" 148 (200)
3/4” 269 (364)
M4 (2) 3
M5 (4.5) 6
M6 (7.5) 10
M8 (18) 25
M10 (37) 50
