Watchman FD-30A - Service Manual Supplement: Cabinet Addition

SERVICE MANUAL
9-963-177-83
SUPPLEMENT
File this supplement with the service manual.
been designed.
Add the following parts to the parts list on page 30 in the FD-30A service
manual.
[ subject Cabinet Addition
The front cabinet (sub) ass’ys with American football team mark have
The reference number is (3) .
GENERAL SECTION
Part No.
X-3316-019-1
X-3316-019-2
X-3316-019-3
X-3316-019-4
X~3316-019-5
X-3316-019-6
X-3316-019-7
X-3316-019-8
X-3316-019-9
X-3316-020-1
X-3316-020-2
X=3316-020-3
X-3316-020-4
X-3316-020-5
X-3316-020-6
X-3316-020-7
X-3316-020-8
X-3316-020-9
X-3316-021-1
X~3316-021-2
X-3316-021-3
X-3316-021-4
X-3316-021-5
X-3316-021-6
Team Description
(PATRIOTS).....CABINET, FRONT
(GIANTS). ..eeee CABINET, FRONT
(JETS) .oeeeee «CABINET, FRONT
(EAGLES).......CABINET, FRONT
(FALCONS).....-CABINET, FRONT
(BROWNS)...... -CABINET, FRONT
(BEARS).......+CABINET, FRONT
(COWBOYS)....-- CABINET, FRONT
(BRONCOS)...... CABINET, FRONT
(LIONS). sesso CABINET, FRONT
(PACKERS)...-0- CABINET, FRONT
(CHIEFS)...+06. CABINET, FRONT
(DOLPHINS)....- CABINET, FRONT
(VIKINGS). .eeee CABINET, FRONT
(SAINTS) .cceeee CABINET, FRONT
(STEALERS).....CABINET, FRONT
(CARDINALS)...-CABINET, FRONT
(BUCCANEERS)...CABINET, FRONT
(REDSKINS)..... CABINET, FRONT
(RAIDERS) ...... CABINET, FRONT
(RAMS). s.eeeeee CABINET, FRONT
(CHARGERS)....- CABINET, FRONT
(49ERS)..ceeeee CABINET, FRONT
(SEAHAWKS)....-CABINET, FRONT
(SUB) ASSY
(SUB) ASSY
(SUB) ASSY
(SUB) ASSY
(SUB) ASSY
(SUB) ASSY
ASSY
ASSY
ASSY
)
)
)
) ASSY
) ASSY
) ASSY
SUB) ASSY
SUB) ASSY
SUB) ASSY
) ASSY
) ASSY
) ASSY
) ASSY
(suB) ASSY
(SUB) ASSY
(SUB) ASSY
(suB) ASSY
(SUB) ASSY
US Model
No, 3
June, 1984
FLAT B/W TV-FM STEREO/AM
Sony Corporation
RECEIVER
SONY.
English
84F0539-1
Printed in Japan
© 1984
