E
Outlet Drain Valve
D
F
G
F
F
F
C
H
Valve Pit
B
Inlet
Drain Valve
A
Main
Shutoff Valve
Figure 1. Components of Series 850 and 860 noted in
the Winter Preparation and Spring Startup procedures.
Ball Valve Draining
Ball valves should also be drained for the winter season in areas
where freezing temperatures may occur. If the valve is left in either
the fully open or the fully closed position, water can become trapped
between the ball and the valve body. And if the trapped water
freezes, damage to the ball valve occurs.
After draining procedures on the backflow prevention assembly have
been completed, all ball valves must be left in the half-open/half-closed,
45 degree position. (Observe this position in Figures 2 and 3.)
Figure 2. Ball valve in half-open/half-closed, 45 degree position.
Open the ball valve approximately 45 degrees to allow water
between the ball and the valve body to drain. Leave the ball valve in
this position for the winter season to prevent freeze damage.
Open and close ball valves slowly at all times to prevent damage to
the system.
The valve must be closed before the system is repressurized.
Figure 3. Cutaway drawing of the ball valve in the 45 degree position.
Limited Warranty: FEBCO (the “Company”) warrants each product to be free from defects in material and workmanship under normal usage for a period of one year from the date of original shipment.
In the event of such defects within the warranty period, the Company will, at its option, replace or recondition the product without charge.
THE WARRANTY SET FORTH HEREIN IS GIVEN EXPRESSLY AND IS THE ONLY WARRANTY GIVEN BY THE COMPANY WITH RESPECT TO THE PRODUCT. THE COMPANY MAKES NO OTHER
WARRANTIES, EXPRESS OR IMPLIED. THE COMPANY HEREBY SPECIFICALLY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for breach of warranty, and the Company shall not be responsible for any incidental, special
or consequential damages, including without limitation, lost profits or the cost of repairing or replacing other property which is damaged if this product does not work properly, other costs resulting from
labor charges, delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions, chemical, or any other circumstances over which the Company has no control.
This warranty shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or alteration of the product.
Some States do not allow limitations on how long an implied warranty lasts, and some States do not allow the exclusion or limitation of incidental or consequential damages. Therefore the above
limitations may not apply to you. This Limited Warranty gives you specific legal rights, and you may have other rights that vary from State to State. You should consult applicable state laws to
determine your rights. SO FAR AS IS CONSISTENT WITH APPLICABLE STATE LAW, ANY IMPLIED WARRANTIES THAT MAY NOT BE DISCLAIMED, INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL SHIPMENT.
USA: T: (800) 767-1234 • FEBCOonline.com
Canada: T: (888) 208-8927 • FEBCOonline.ca
Latin America: T: (52) 55-4122-0138 • FEBCOonline.com
IOM-F-FreezeProtection 2344 © 2023 Watts
