81-(617',-0+6,)5-()51*6,)37%46<5.))8)%0(.%/2,%0(.)&;6,))0(510.;
6)2 Disconnect power.
6)2 Turn water off and open valve down stream of system to relieve pressure.
6)2 Remove vinyl cap and unscrew the nut.
6)2 Carefully withdraw lamp approximately 2 inches from chamber.
6)2 While holding lamp end carefully remove lamp socket on end now exposed.
)26 Carefully withdraw lamp from chamber.
6)2 Carefully remove O-ring from the end of quartz sleeve.
6)2 Carefully remove quartz sleeve.
6)2 To reinstall follow steps 8 through 1 in reverse.
!
To operate the sterilizer properly and attain its maximum efficiency it is recommended that the user performs the following maintenance:
1. Quartz sleeve cleaning or replacement:
a. Quartz sleeve is to be cleaned every 6 -12 months. Clean with glass cleaner.
b. Quartz sleeve is to be replaced every 24 months.
2. UV lamp replacement is recommended every 8000 - 9000 hours or operation (approx. 12 months of continuous service).
! Ultraviolet lamp and quartz sleeve are easily damaged. Pay attention when removing or replacing lamp and quartz sleeve!
$
# Germicidal ultraviolet rays are harmful to eyes and skin.
!
1 Ballast Assembly WUVBALLAST2 (or 6, 8, 12) available in 110V or 230V
2 Germicidal Ultraviolet Lamp WUVLAMP2 (or 6, 8, 12)
3 Rubber O-Ring T1200-0116
4 Quartz Sleeve WUVQS2 (or 6,8,12)
5 Chamber N/A
6 Mounting Clip C2500W
