HEADQUARTER™
copyright © 2020 wavebone Taiwan All rights reserved
1STEP
1
A
F
5
A
2
E
D
5
Please follow the instruction for desk installation and check whether there is any
component missing before installation
1F
Please ensure that 4 screws are
located in correct positions, then
tightened every screws.
Z shape height adjustable
keyboard desk
1
x16
M5(10mm)
2
x4
M6(15mm)
4
x4
M6(48mm)
5
x2
M6(63mm)
3
x3
M6(30mm)
6
x1
M4
7
x1
M3
A B C
D
E
F
x2 x1
x1
x1
x1 x4
x2
x4
x16
2STEP
2
5
D
E
x1
x1
x4
x2
2
Loose the pre-lock screws and
tightened them to the holes
according to your prefered heights.
To Next Page
