BME280 Environmental Sensor
INTERFACES
I2C
PIN
Arduino
STM32
RASPBERRY
Description
VCC
3.3V/5V
3.3V /5V
3.3V /5V
Power
GND
GND
GND
GND
Ground
SDA
A4
PB7
SDA
I2C Data
SCL
A5
PB6
SCL
I2C Clock
ADDR
NC/GND
NC/GND
NC/GND
Address Select (High by default)：
High：address is 0x77
Low：address is 0x76
CS
NC
NC
NC
NC
SPI:
PIN
STM32
RASPBERRY
Description
VCC
3.3V /5V
3.3V /5V
Power
GND
GND
GND
Ground
MOSI
PA7
MOSI
SPI Data input
SCK
PA5
SCK
SPI Clock input
MISO
PA6
MISO
SPI Data output
CS
PB6
27
SPI chip select, Low active
