Waveshare VL53L0X User Manual

VL53L0X Distance Sensor User Manual
Version: V1.0.0, Date: 2018.06.27 2
➢ Mounting holes size: 2.0mm
➢ Ranging distance: 30 ~ 2000mm
➢ Ranging accuracy: ±5% (high speed mode), ±3% (high accuracy mode)
➢ Ranging time (min): 20ms (high speed mode), 200ms (high accuracy mode)
➢ Field of view: 25°
➢ Laser wavelength: 940nm
➢ Operating temperature: -20 ~ 70°C
PINOUTS
VCC: 3.3V/5V power input
GND: ground
SDA: I2C data pin
SCL: I2C clock pin
SHUT: shutdown control, connects to IO pin
INT: interrupt output, connects to IO pin
