2 Operating Controls Operating instructions DUO 315
(05.11) KS_DUO 315_BA_04_701474600_00.doc
2
2 Operating Controls
1 Power Switch (on side of case)
2 Welding Socket
3 Display
4 Start / Stop Button (Reset on side of case)
5 Temperature Sensor
6 Supply Cable
7 Welding Cable
2 1 3 4
5 6 7
