Operating instructions DUO 315 9 Multiple Welds
(05.11) KS_DUO 315_BA_04_701474600_00.doc
7
9 Multiple Welds
In Green mode, the unit can simultaneously weld multiple fittings
connected in series using the optional green link cable.
The combined diameters of the fittings to be joined must not exceed
200mm. For example, a 45
o
75/50mm tee can have both main pipe
75mm fittings and the branch 50mm fitting welded together:
75mm + 75mm + 50mm = 200mm
Link Cable
Link Cable
Welding Cable
