Notes: All specifications are subject to change without notice.
1) All enclosure information assumes no leaks with normal fill (interior walls covered with acoustic damping material).
2) External dimensions, driver and port displacement for net volume are based upon all 3/4" thick enclosure construction.
3) A -24dB/oct. subsonic filter set at or below the tuning frequency (Fb) is recommended to prevent over-excursion.
4) Minimum recommended port area is 15.9in (103cm), or round equivalent port diameter of 4.5” (11.4cm). More port
area and/or flaring is preferred when feasible, particularly for a larger enclosure with lower tuning frequency (Fb).
5) Small or irregular shape enclosures may require at least one internal bend or an external port to fit required length.
0.6ft Sealed
Enclosure
1.0ft Ported
Enclosure
Cut-List for 3/4” Sheet:
Front/Back: (2) 20” x 14”, Top/Bottom: (2) 20” x 4-1/2”, Sides: (2) 12-1/2” x 4-1/2”
Cut-List for 3/4” Sheet:
Front/Back: (2) 36” x 18-1/2” • Top/Bottom: (2) 36” x 4-1/4” • Sides: (1) 12-1/2” x 4-1/4” and (1) 17” x 4-1/4”
Slot Shelf/Corner: (1) 31-1/2” x 4-1/4”, (1) 4-1/2” x 4-1/4” and (1) 4-1/8” x 4-1/4” with 45° chamfers/miters as shown
11-1/8"
4-1/8"
31-1/2"
36"
17"
18-1/2"
4-1/2"
34-1/2"
12-1/2"
3-3/4"
5-3/4"
4-1/4"
14"
11-1/8"
12-1/2"
20"
18-1/2"
6"
4-1/2"
Recommended Range Net Internal Volume, Qtc
Internal Dimensions
Net Internal Volume
F
3
, ripple, Qtc
39Hz, +0.5dB, 0.86 42Hz, +0.2dB, 0.8
Recommended Range Net Internal Volume, Fb
Internal Dimensions
Port Opening Dimensions
F
3
, ripple, Fb
28Hz, +3.4dB, 31Hz 28Hz, +2.4dB, 31Hz
17 "H x 34-1/2"W x 4-1/2"D (43.2 x 87.6 x 10.8cm)
0.8-1.5 ft
3
(22L-42L), 22-35Hz
14"H x 20"W x 6"D (35.6 x 50.8 x 15.2cm)
0.4-1.0 ft
3
(11-28L), 0.7-1.0
Recommended Enclosure Alignments
18.5 "H x 36W" x 6"D (47 x 91.4 x 15.2cm)
3-3/4"H x 4-1/4"W (9.5x10.8cm)
0.43ft
3
(12.2L), incl. 45° corner insert
12-1/2"H x 18-1/2"W x 4-1/2"D (31.8 x 47 x 11.4cm)
Sealed, Ported and Bandpass
