Skoda Superb
1314084D_EN
2
Table of Contents
Validity
Vehicle and engine types, equipment variants and national specifications not listed in these installation
instructions have not been tested. However, installation according to this installation documentation
may be possible.
The installation location of a digital timer and summer/winter switch should be confirmed with the end
customer before installation.
Manufacturer Model Type EG-BE No./ABE
Skoda Superb 3T e11 * 2001/116 * 0326 * ...
Engine type Engine model Output in kW Displacement in cm³
CBBB Diesel/Common Rail 125 1968
Validity 2
Heater / Installation Kit 3
Foreword 3
General Instructions 3
Special Tools 3
Explanatory Notes on Document 4
Preliminary Work 5
Heater installation location 5
Electrical system 6
Preparing fuse holder and K3 relay 7
Climatic fan controller 8
Climatronic fan controller 10
Remote option Telestart 12
Premounting heater 13
Premounting combustion air pipe 13
Premounting exhaust pipe 14
Premounting coolant hoses 15
Coolant circuit 18
Preparing hose routing 19
Hose routing 21
Preparing installation location 24
Installing heater 24
Fuel 27
Exhaust gas 30
Final Work 31
Adjusting the sensitivity of the
passenger compartment monitoring 31
Operating Instructions for End Customer 32
