PARTS LIST - WEBC33 Engine
Item No. Webb Part No. Webb Descripon Qty
Item No. Webb Part No. Webb Descripon Qty
1 WE02050070024 Recoil Assembly 1
31 WE03010010077 Bolt M5x55 2
2 WE03020020012 Screw M5x20 8
32 WE02050010139 Exhaust 1
3 WE02010030018 Gasket 1
33 WE02070010146 Exhaust Gasket 1
4 WE02050100006 Starter Pawl 1
34 WE02050030230 Ignion Coil 1
5 WE02050120002 Fuel Filter 1
35 WE02050050181 Wire 1
6 WE61330010013 Inlet Fuel Pipe 1
36 WE03090020020 Needle Bearing 1
7 WE70050030171 Fuel Tank 1
37 WE02020030016 Piston Pin Retainer 2
8 WE61330010018 Outlet Fuel Pipe 1
38 WE02010020009 Piston 1
9 WE03100010009 Oil Seal 12x22x7 2
39 WE02020010006 Piston Pin 1
10 WE70070050112 Rear Crankcase 1
40 WE02020020006 Piston Ring 2
11 WE02070010230 Crankcase Gasket 1
41 WE02070010034 Cylinder Gasket 1
12 WE03090010034 Bearing 6201/P5 2
42 WE70070130069 Cylinder 1
13 WE02020120031 Cranksha Assembly 1
43 WE03010010062 Screw M5x20 4
14 WE03070010002 Woodruff Key 3x5x13 1
44 WE03130010013 Spark Plug RCJ6Y 1
15 WE70070050078 Front Crankcase 1
45 WE70030030854 Engine Cowling 1
16 WE03060010004 Pin 4x10 2
46 WE02070010092 Insulator Gasket 1
17 WE03040020018 Washer 8 - GB/T97.1 1
47 WE70030020011 Insulator 1
18 WE03050010008 Washer 8 - GB/T93 1
48 WE02070010072 Carbureor Gasket 1
19 WE03010010069 Screw M5x30 4
49 WE02050020016 Carbureor 1
20 WE02050030046 Flywheel 1
50 WE70080120007 Air Filter Housing 1
21 WE03030010017 Nut M8x1.25 1
51 WE03020020047 Screw M5x50 2
22 WE03040050048 Gasket B 2
52 WE02090010011 Air Filter 1
23 WE02050160006 Clutch 1
53 WE70030040226 Air Filter Cover 1
24 WE03040050043 Washer 2
54 WE02110030079 Air Filter Knob 1
25 WE02020130003 Clutch Step Screw 2
55 WE03020020027 Screw M5x16 3
26 WE70070030044 Cover 1
56 WE03040050022 Washer φ5*15*1 3
27 WE03010010062 Screw M5x20 4
57 WE03010110057 Screw M5x8 1
28 WE03020020053 Screw M5x12 - GB/T9074.4 2
58 WE03040020020 Washer φ5 - GB/T97 1
29 WE02080030042 Rubber Stopper 1
59 WE02020160764 Plate 1
30 WE02110020026 Fuel Cap 1
PARTS DIAGRAM - WEBC33 Engine
