FITTINGCOWHORNHANDLES(WEBC33&WEBC43)
1. Installhandleonlowerbracket.
2. Positionhandleinacomfortableoperating
position
3. Fitupperbracket.
4. Tightenthefourfixingscrews.


FITTINGD-HANDLE(WEBC26Only)
1. Placetophandleontodriveshaft.
2. Positionlowerhandle,beneaththetophandle
inacomfortableoperatingposition
3. Tightenthefourfixingscrews.



FITTINGTHEMETALBLADE
1. InstallholderA,theblade,holderB,tooth
washer,inthisorder
2. Thenclampwiththeleft-handthreadnut.
3. AlignholeofgearcaseandholderA,andinsert
AllenKey.
4. Rotatelefthandthreadnutwithspannerin
clockwisedirectionuntilsecurelytightened.
5. InstalltheSplitPin2×16andsplitlegstosecure.


REPLACINGYOURNYLONLINE
1. Cut3metresof2.5mmdiameterNylonLine.
2. Alignthearrowsonthefeed/bumpknobwith
theeyelets.
3. Feedthelineintothefeedpipe(supplied).
4. Feedthefeedpipe&lineinthroughthefirst
eyeletandoutofthesecondeyelet.
5. Removethefeedpipeandputinasafeplace.
6. Pullthenylonlineuntilyouhavetwoequal
lengths.
7. Nowrotatethefeed/bumpknobCLOCKWISE,to
windthenylonlineintothehead.
8. Stopwhenyouhave150mmofnylonline
protrudingfrombotheyelets.

 


WARNING
Excessivevibrationofthemetalbladeindicatesithasnotbeeninstalledcorrectly.
Stoptheengineimmediately,checkthebladeinstallationandre-installcorrectly.Anincorrectlyinstalledblade
cancauseinjury.


NylonHead
NylonLine
FeedPipe
