Webb WEBV26 - PARTS DIAGRAM - WEBV26 Engine

PARTS LIST - WEBV26 Engine
Item No Webb Part No. Handy Descripon Qty
Item No Webb Part No. Handy Descripon Qty
1 WE03130010013 Spark Plug RCJ6Y 1
24 WE02050030018 Flywheel 1
2 WE03010010061 Bolt M5X20 4
25 WE02070010078 Insulator Gasket 1
3 WE70070130011 Cylinder 1
26 WE02110030031 Insulator 1
4 WE02070010020 Cylinder Gasket 1
27 WE03020020012 Bolt M5X20 2
5 WE02020020003 Piston Ring 2
28 WE02070010061 Carburretor Gasket 1
6 WE02010020006 Piston 1
29 WE02050020045 Carburetor 1
7 WE02020010004 Piston Pin 8X28 1
30 WE70030040038 Choke Lever 1
8 WE02020030017 Snap Ring 2
31 WE70080120007 Air filter Housing 1
9 WE03090020018 Needle Bearing 1
32 WE70030040028 Choke 1
10 WE02020150007 Thrust Washer 2
33 WE03010040008 Bolt ST4×10 1
11 WE02020120026 Cranksha Assembly 1
34 WE02090010011 Air filter Housing 1
12 WE03090010028 Bearing 6001/P5 2
35 WE03020020030 Bolt M5X60 2
13 WE03060010002 Pin B3X10 2
36 WE70030040078 Air Filter Cover 1
14 WE02070010110 Crankcase Gasket 1
37 WE70030180012 Air Filter Screw 1
15 WE03050010014 Rear Crankcase 1
38 WE02070010141 Exhaust Gasket 1
16 WE03100010009 Oil Seal 12X22X7 2
39 WE02050010018 Exhaust 1
17 WE03120030003 Stop Ring 2
40 WE03040020019 Washer 5 2
18 WE02050100015 Starter Pawl 1
41 WE03050010014 Washer 5 3
19 WE02020110088 Starter Pawl Spring 2
42 WE03010010049 Screw M5X50 2
20 WE70030140015 Starter Pawl 2
43 WE03040010007 Washer 4 2
21 WE03070010002 Woodruff Key 1
44 WE02070010048 Spacer 2
22 WE70070050001 Crankcase - Front 1
45 WE02050050141 Stop Wire 1
23 WE03010010045 Bolt M5X30 3
46 WE02050030024 Ignion Coil 1
47 WE03020020013 Screw M4X20 2
PARTS DIAGRAM - WEBV26 Engine
WEBV26 193867001 IM.indd 16 06/07/2016 09:07
