BLOWER ASSEMBLY
1. Match Blower Tube A, with the locking stubs on the body of the machine.
2. Rotate the tube clockwise to lock into place.
3. Repeat the same acon aaching Blower Tube B to Blower Tube A.
4. Secure Blower Tube A to the body of the machine, using M5x10 screw.
WARNING
EXCESSIVE VIBRATION OF THE MULCHING FAN INDICATES IT HAS BEEN DAMAGED. CONSULT YOUR LOCAL
APPROVED DEALER FOR ASSISTANCE
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents of the lawnmower contact us:
Tel: 01793 333212 - Mon – Fri 8.30am – 5.00pm (excl. Bank Holidays)
Email: customerservice@webblawnmowers.co.uk
VACUUM ASSEMBLY
1. Open the fan cover, by loosening the top screw and allowing the fan cover to open.
2. Match Sucon Tube A, with the top & boom locking stubs on the body of the machine.
3. Rota
te the tube clockwise to lock into place.
4. Repeat the same acons, aaching Sucon Tube B to Sucon Tube A.
5. Insert the Discharge Tube into the Collecon Bag and secure.
6. Connect the Discharge Tube to the Discharge Outlet of the machine and secure with an M5x10 screw
