SERVICE INFORMATION
Repair manual CF 2 + CF 3
Mount the inner bearing ring (1) onto the
eccentric shaft (2).
Insert the eccentric into the exciter housing.
Use the fastening screws to arrange the housing cover
such that the drill holes line up on top of each other.
Fit the housing cover into the exciter housing.
