Weber mt CF 2 - 2.4.3 Fitting the Damper Plate; 2.4.4 Fitting the Undercarriage

13
1
2
1
1
SERVICE INFORMATION
Repair manual CF 2 + CF 3
Lift the top section (1) of the machine onto the
base plate (2).
Slide the top portion of the V-belt (1) into the slotted
holes in the specied direction.
Fit and tighten the V-belt.
Tighten the screws of the top section.
