SERVICE INFORMATION
Repair manual CF 2 + CF 3
Drain oil.
Select a collection vessel that is large enough to pre-
vent oil from spilling on the ground. Dispose of waste
oil in an environmentally friendly manner (regulation
on waste oils).
Wipe up / off oil slick and oil residue and dispose of
fuel-soaked cleaning cloths in an environmentally
responsible manner.
Remove the screws (1).
Remove the V-belt guard (1).
Lift off the top section.
Remove the oil drain screw.
