Installing the test unit
1 Connect the Tester to the circuit (see inside back cover for port sizes). The preferred flow
direction is indicated by the larger arrow on the panel. Use hoses and fittings of sufficient
diameter for the flow being tested. Avoid restrictions at inlet and outlet ports of the Tester.
Also avoid sharp bends because high pressure hoses will deflect and straighten under
pressure.
2 Ensure that the pressure loading valve is fully opened by turning the knob counter
clockwise.
3 Switch the unit on. On digital models if the display flashes, or on analogue models if the
needle points to the symbol, then the battery needs replacing.
4 Select the desired test using the front panel controls (not applicable on 1 series)
5 When low pressure testing is required, connect the optional low pressure gauge with
automatic cut-out valve to the tester block.
Note: the test point can be connected by hand at full pressure.
Accessories
For 2 series testers only INFRARED PHOTO TACHOMETER comprises infrared photo tach
head, six metre connecting cable and reflective tape. The BA20 magnetic base with flexible arm
is also available, this is used to secure the tacho head on the machine.
Note: The Photo-Tachometer should not be plugged in when the unit is already switched
on. First switch off the tester, plug in the Tacho and then switch the tester back on. Only
Webtec supplied Photo-Tachometers labelled FT9251 ISSUE B should be used with this
tester. Using other brands or earlier unlabeled versions, however similar they may appear,
could cause permanent damage to the Tester and or Photo-tachometer.
For all models of tester LOW PRESSURE GAUGE KIT comprises 63 mm Glycerine filled 40
bar (600 psi) gauge with automatic cut-out valve, pressure test point and 300 mm (12”) long
micro bore hose. The test point is fitted permanently into the tester block and the low pressure
gauge can be connected by hand without the need to stop the machine.
ADAPTORS. Fitting kits are available for all testers. Consult Sales Office.
