Remote Flow blocks available for all models:
Consult sales office for details
Temperature 10 - 120 °C (50 - 250 °F)
Internal & External
Speed 300 - 6000 rpm
TH3 Photo Tacho.
Gauge 1/4” BSPF (English) 1/4” NPT (American)
Accuracy
Flow 1% of indicated flow reading over the top 85%
of the range in the preferred flow direction.
Reverse flow testing 1% full scale. Flowmeter
calibrated with mineral oil, viscosity 21
centistokes.
Speed Above minimum speed rating 1% of maximum
speed
Pressure Within 1.6% of full scale
Temperature ± 1 °C
Battery
Tester 9 Volt battery, size 18 x 25 x 43 mm. PP3 (UK),
64F22
(Europe), 6AM6 (Japan) A1604 (USA)
Note: Tester Displays lpm, USgpm and IMPgpm. *Consult sales office for intermittent operation up to 420 bar, 6,000 psi.
Specification
Pressure Gauge, 0 - 420 bar / 0 - 6000 psi
Working
Ports
Models Pressure Flow Range
(bar) (lpm) English American
DHCR 60 0 - 420 3 - 60 Tester inlet/outlet 3/4”-14 BSPF Tester inlet/outlet 1” 1/16-12 UNF SAE O-Ring
DHCR 150 0 - 420 5 - 150 Loading valve outlet 1/2”-BSPF Loading valve outlet 3/4”-8 UNF SAE “O”Ring
DHT & DHCR 302 0 - 420 8 - 300
1”-12 BSPF Parallel 1”5/16-12 UNF SAE “O” Ring
DHT & DHCR 402 0 - 420 10 - 400
DHT & DHCR 602-F 0 - 350* 20 - 600 1” 1/2 SAE type four bolt flange
DHT & DHCR 802-F 0 - 350* 20 - 800 Solid 350 bar/5000 psi, Split 200 bar/3000 psi
DHT & DHCR 802-S 0 - 480 20 - 800 1” 7/8 UNF
