Note:
When installing the electronic module,
please lock screws properly to fix
electronic module in position, and
prevent deforming the electronic bracket.
9g Servo Motor- RJ11 Adapter Module
RGB Ultrasonic Sensor V1.0- Port A
4 Digital LED Module- Port B
RJ11 Adapter Module- Port C
4x Screw M4*20
2x Screw M4*20
2x Screw M4*20
2x Screw M4*8
2x Screw M4*8
4x Nut M4
4x Nut M4
1x RGB Ultrasonic Sensor V1.0
1x RGB Ultrasonic Sensor V1.0
1x RJ11 Adapter Module
1x RJ11 Adapter Module
1x 4 Digital LED Module
1x4 Digital LED Module
3x RJ11 Cable - 20cm
3x RJ11 Cable - 20cm
4 Digital LED Module→
RJ11 Cable-20cm→Port B
RJ11 Adapter Module→
RJ11 Cable-20cm→Port C
9g Servo→RJ11 Adapter Module
4 AA Battery Holder
RGB Ultrasonic Sensor V1.0→
RJ11 Cable-20cm→Port A
Assembly Guide - Parking Lot System
