Hand slide valve
As an alternative to manual application of the pilot pressure, a hand slide valve is avail-
able.
Part No� Description Port P1 Port P2
C1-48091 Hand slide valve
G1/8“ female
thread
G1/8”
male thread
E69-96824 Thread extension
G1/8“ female
thread
G1/8”
male thread
Spare parts
The following parts are available for maintenance of the WEH
®
Product:
Part No� Description
On request
Main seal sets (contain the elastomer main seal(s), two back-up washers
and a retaining ring)
On request
Replacement seal sets (contain five complete main seals with retaining
rings)
Î
When ordering, please indicate the part no. marked on the WEH
®
Product.
Please note: For the correct use of WEH
®
Spare parts, please refer to Chapter 3. Prod-
uct overview / product description on page 10.
MD-10187-L51-R1.3.0-03
Page 35
Operating instructions
