Weidmüller UCV/AR - Page 25

25
Analogue outputs
Analogue
Output type
OP=I
OP=E
Current based output
Voltage based output
Toggle Accept
Analogue output
range
OPL=
4.00
Output low value
e.g., 4.00
-
Dec
-
Inc
Next
Accept
OPH=
20.00
Output high value
e.g., 20.00
-
Dec
-
Inc
Next
Accept
Output action
OP=d
OP=r
Direct
Reversed
Toggle Accept
Calibrate
Output?
COPn
COPY
Skip output calibration
Calibrate outputs
Toggle Accept
Save values
SAVE
Instrument is saving the changes to the setup and returning to normal
operation
Setup Sequence (continued)
