1.1 Hardware Introduction
1.1.1 A Picture of NK280
Fig. 1-1 A picture of NK280
1.1.2 System configuration
NK280 integrated system consists of the following components:
 One host of NK280
 One EX9A4 or EX24A2 terminal board
 One DB9M/F cable (length custom)
 Servo cable (brand, length and quantity decided by customers)
 NK-MPG-06 Handwheel (optional)
Note:
The above lists the system components of standard configuration and the final receiving should be subject to the
receipt list.
The extended terminal board EX26A is optional.
1.1.3 Mounting Dimension
After NK280 is installed on the machine tool, 100 mm space should be preserved in its surrounding
for wiring convenience. Please ensure ventilation in the cabinet. And the mounting dimension is shown
in Fig. 1-2:
