WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused - 129 -
Para. No.
Parameter
Name
Value
Description
prohibited will not occur (NO.7).
2: Invalid stroke end of LSP, LSN positive rotation,
negative rotation, and SON is forced to be effective.
(Note: SON forcedly effective is only used for motor
debugging. In normal use, we suggest controlling the
state of SON by input port.)
3: Valid stroke end of LSP, LSN positive rotation,
negative rotation.
When switch LSP is connected, driving of the positive
rotation is allowed; When switch LSP is disconnected,
driving of the positive rotation is prohibited (the speed
of positive direction is 0, but the torque is not 0). LSN
is the same as LSP. When LSP and LSN are all
disconnected, abnormal alarming of driving prohibited
will not occur (NO.7).
