Weiro ARC-400 - Components Lists

ARC-E 400
5
3. Components List
 ARC315E /400E
No.
Tab
Item
Stock No.
Quantity
1
QB1
Circuit breaker
745011-00049
1
2
C1～C3
Polypropylene capacitor
722001-00023
3
3
Q1、Q2
IGBT module
735007-00046
2
4
TB1
3-phase rectifier module (small)
735005-00009
1
5
RE1
Varistor
720021-00017
1
6
C4
Polypropylene capacitor
722001-00070
1
7
A3
IGBT protection board
220005-00056
1
8
BE1
Power Inductor
220149-00070
1
9
RA1
Resonance Inductor
220521-00037
1
10
C7
Polypropylene capacitor
722001-00073
1
11
T1
Main transformer
220629-00090
1
12
RA2
Current exchange inductor
220281-00021
1
13
RB1、RB2
Fast recovery diode module
735006-00027
2
14
GQ1
Fan
746001-00011
1
15
FA1
Fuse
745007-00012
1
16
T2
Transformer for ZKB/QDB
763001-00136
1
17
A1
Main control board
210580-00362
1
18
A2
Drive board
210310-00069
1
19
BB1
Thermal
745008-00006
1
20
BB2
Thermal
745008-00008
1
21
Digital displayer
755001-00003
1
22
Potentiometer
720031-00030
1
23
Potentiometer
720031-00042
2
Table 2: Components List for ARC315E/400E
