Installation and operating instruction
Gas burner WG10…/0-D ZM-LN
7 Commissioning
83300902 1/2019-02 La
56-112
10. Adjust partial load
Press[G] and [L/A] keys simultaneously.
Burner drives to partial load.
The lower operating limit is displayed (bu).
Define partial load whilst observing:
data supplied by boiler manufacturer,
burner capacity graph [ch.3.4.6].
Determine gas throughput, if necessary adjust partial load(bu) using[+] key.
Press[G] and [L/A] keys simultaneously.
Combustion manager changes to operating level (10).
Combustion manager is programmed.
11. Check start behaviour
Switch off and restart burner.
Check start behaviour and if necessary correct operating point P0 (ignition pos-
ition).
If the ignition position has been altered:
Re-check start behaviour.
