OPERATING INSTRUCTIONS FOR GAMBIT DE-ESSER/COMPRESSOR DS1-MK3 TECHNICAL DATA
Weiss Engineering Ltd., Florastr. 42, CH-8610 Uster Page 31
+41 44 940 20 06 +41 44 940 22 14 http://www.weiss.ch weiss@weiss.ch
Monitor Control Change 1011 cccc 00010100 ($2B) (cccc) Channel No.
0vvv vvvv (vvvvvvv) New Value:
0= off, 1 = on
System Reset 1111 1111 - Recall Snapshot 0 to WS A
System Exclusive
Snapshot format:
Bytecount
Value Description
1 F0 Sysex Header
2 00 Manufacturer's ID
3 30 Manufacturer's ID
4 5A Manufacturer's ID
5 08 Model ID: $0C = Gambit DS1-MK3
6 0000nnnn Device ID: -> Midi channel number
7 00000001 message = Snapshot dump Message Type 1
8 0nnnnnnn Package number ( 0..7F) Data
9 0nnnnnnn scale set number
10 - 24 0nnnnnnn 15 Bytes of Snapshot data
25 0ccccccc Checksum without byte one (F0 Sysex Command) Checksum
26 F7 EOS EOS
Dump request:
Bytecount
Value Description
1 F0 Sysex Header
2 00 Manufacturer's ID
3 30 Manufacturer's ID
4 5A Manufacturer's ID
5 08 Model ID: $0C = Gambit DS1-MK3
6 0000nnnn Device ID: -> Midi channel number
7 00000010 message = dump request Message Type 2
8 F7 EOS EOS
Version request:
Bytecount
Value Description
1 F0 Sysex Header
2 00 Manufacturer's ID
3 30 Manufacturer's ID
4 5A Manufacturer's ID
5 08 Model ID: $0C = Gambit DS1-MK3
6 0000nnnn Device ID: -> Midi channel number
7 00000011 message = version request Message Type 3
8 F7 EOS EOS
