Wel-Bilt M141300A - Page 43

Engine Parts Breakdown – Exploded View 141300 Rev. A
43
Item
Description
Part #
Qty
Item
Description
Part #
Qty
1
Crankcase
N/A
1
43
Pin, Dowel
N/A
2
2
Ball bearing
N/A
2
44
Bolt
N/A
6
3
Oil Seal
N/A
2
45
Gasket, Cylinder Head
N/A
1
4
Governor Assembly
N/A
1
46
Bolt
N/A
4
5
Shaft, Governor Arm
N/A
1
47
Spark Plug
786736
1
6
Washer, Governor Arm Shaft
N/A
1
48
Rod, Push
N/A
2
7
Pin, Lock
N/A
1
49
Shroud
N/A
1
8
Bolt, Drain Plug
Kit # 3
2
50
Bolt
Kit # 5/# 8
13
9
Washer, Drain Plug
Kit # 3
2
51
Packing, Head Cover
Kit # 5
1
10
Switch Assembly, Oil Level
N/A
1
52
Cover Comp, Cylinder Head
Kit # 5
1
11
Bolt
Kit # 7
5
53
Wind Shield Comp.
N/A
1
12
Dowel pin, Case Cover
N/A
1
54
Bolt
N/A
1
13
Dowel pin, Case Cover
N/A
1
55
Flywheel Assembly
N/A
1
14
Piston
N/A
1
56
Fan, Recoil Starter
Kit # 8
1
15
Scraper Ring Set ,Piston
N/A
1
57
Pulley, Starter
Kit # 8
1
16
Rod Assembly, Connecting
N/A
1
58
Nut M14
Kit # 8
1
17
Pin, Piston
N/A
1
59
Ignition Coil Assembly
Kit # 6
1
18
Clip, Piston
N/A
2
60
Clip
N/A
2
19
Cover Assembly, Crankcase
N/A
1
61
Bolt
Kit # 6
2
20
Oil Plug
N/A
1
62
Packing, Intake
Kit # 2
1
21
Cylinder head
N/A
1
63
Insulator, Carburetor
Kit # 2
1
22
Valve, In
N/A
1
64
Packing, Carburetor
Kit # 2
1
23
Valve Exhaust
N/A
1
65
Spacer, Carburetor
Kit # 2
1
24
Returner, Intake Valve
N/A
1
66
Rod, Governor
N/A
1
25
Spring, Valve
N/A
2
67
Spring, Throttle Return
N/A
1
26
Seat, Valve Spring, In
N/A
1
68
Recoil Starter Assembly (Black)
Kit # 8
1
27
Seat, Valve Spring, Ex
N/A
1
69
Switch Assembly
Kit # 8
1
28
Plate, Push Rod Guide
N/A
1
70
Shroud Assembly, Upper
N/A
1
29
Rocker Assembly
N/A
2
71
Speed Regulating Handle
N/A
1
30
Cap
N/A
1
72
Air Cleaner Assembly
Kit # 1
1
31
Bolt, Stud
Kit # 2
2
73
Tube, Breather
Kit # 1
1
32
Bolt, Stud
Kit # 4
2
74
Clip
N/A
1
33
Carburetor Assembly
Kit # 2
1
75
Spring, Governor
N/A
1
34
Fuel line
Kit # 7
1
76
Amplifier
N/A
1
35
Clip, Fuel Line
Kit # 7
2
77
Packing, Exhaust
Kit # 4
1
36
Governor Arm
N/A
1
78
Muffler
Kit # 4
1
37
Bolt, Governor Arm
N/A
1
79
Nut M8
Kit # 4
2
38
Nut
Kit # 1
3
80
Spring Washer
Kit # 4
2
39
Crankshaft Assembly
N/A
1
81
Dipstick
N/A
1
40
Lifter, Valve
N/A
2
82
Fuel Tank Assembly (Black)
Kit # 7
1
41
Packing, Case Cover
N/A
1
83
Fuel Cock
Kit # 7
1
42
Camshaft Assembly
N/A
1
84
Spring Washer
Kit # 7
3
