Part Number STH098 06/19 89
ICE MACHINE CYCLES INTO HARVEST BEFORE THE
HARVEST FLOAT IS DOWN/CLOSED
Step 1 Disconnect power to the ice machine, remove
the electrical panel to allow viewing of the control board
lights and pull the wire connector for the harvest float
switch through the bulkhead and disconnect.
WIRE CONNECTORS ARE LOCATED BEHIND BULKHEAD
PULL THROUGH GROMMET TO DISCONNECT
HARVEST FLOAT
SWITCH & BRACKET
ICE THICKNESS FLOAT
SWITCH & BRACKET
,
Caution
Do not disassemble a float for descaling/sanitizing or
troubleshooting. The float magnet is not located in the
center of the float and incorrect reassembly will result
in an ice machine that will not harvest.
To Next Page
