Disassembly Guide
Required Tools:
- 1/8” Allen wrench
- 5/32” Allen wrench
- 3/8” wrench
- 7/16” wrench
- 3/8” socket
- 7/16” socket
- 11 mm socket
- Ratchet socket driver
- #1 Phillips screwdriver
- Slotted screwdriver
- 1/8” slotted screwdriver
Specified Torque Values
Screw
Description
Installation Material
Torque Specification
Bit Type
¼-20 x 1/2 BHSC
Aluminum
30.0 in-lbs. max.
5/32” Hex
