Welch Allyn CP 100 Directions For Use

Directions for Use Chapter 1 Introduction 11
Moving Through the Menus
Figure 9. Standard Menu Figure 10. Parent Menu With Submenu
Desired Actions Keys to Press
To move up or down a list or
To open a standard menu (Figure 9)
To move from parent menu to submenu on same
screen (Figure 10)
or
or item’s number or letter
To perform an action
To accept data
To check or uncheck a checkbox
To return to parent menu from submenu on same
screen (Figure 10)
or
To move back through the menus or zero key
To move through data-entry fields or
To return to the Ready screen from a standard menu
(Figure 9)
Edit Auto Report
9:17AM Oct 16 08
1 Format
2 Interp Settings
3 Patient Data
0 Previous Menu
Format
9:17AM Oct 16 08
1 Lead Arrangement
2 Rhythm Lead 1
3 Rhythm Lead 2
4 Rhythm Lead 3
5 Extended Measurements
6 Average Cycles
0 Previous Menu
3x4 +1R
3x4 +3R
6x2
12x1
6x2 50 mm/s
6x2 10 Ext.
2x6+1R
(To select the highlighted submenu
item.)
(To make no change.)
