EXPLODED VIEW & PARTS LIST
No. Model No. Description Qty.
1 2289-001 Pump Assembly 1
2 2289-002 Rubber Foot 2
3 2289-003B Shroud Front 1
4 2289-004B Shroud Rear 1
5 2289-005 Air Filter Intake Housing 1
6 2289-006 6' Power Cord 1
7 2289-007 Pressure Switch 1
8 2289-008 Pressure Gauge 2
9 2289-009 Safety Valve 1
10 2289-010 Drain Valve 1
11 2289-011 Check Valve 1
12 2289-012 Regulator 1
13 2289-013 Quick Connect Fitting 1
14 2289-014 Nipple 35mm 1
15A 2289-015A
Vertical Pipe Nipple
Assembly
1
16 2289-016 Exhaust Elbow 1
17 2289-017 3/8" Ferrule Tubing 2
18 2289-018 1/4" Ferrule Tubing 2
19 2289-019 3/8" Nut 2
20 2289-020 1/4" Nut 2
14
No. Model No. Description Qty.
21 2289-021 Relief Tube 1
22 2289-022 Outlet Tube 1
23A 2289-023A 10-Gallon Tank 1
24 2289-024 Handle 1
25 2289-025 Rubber Grip 1
26 2289-026 Wheel 2
27 2289-027 Bolt M10x1.25x55 2
28 2289-028 Hex Bolt M8x1.25x25mm 4
29 2289-029 Hex Bolt M8x1.25x20mm 6
30 2289-030 Hex Bolt M6x1.0x20 2
31 2289-031 Hex Bolt M6x1x12mm 6
32 2289-032 Hex Nut M8 6
33 2289-033 Nylon Hex Nut M10x1.25 2
34 2289-034 Flat Washer M10 2
35 2289-035 Flat Washer 6mm 2
36 2289-036 Flat Washer 8mm 8
37 2289-037 Lock Washer 6mm 2
38 2289-038 Lock Washer M8 8
39 2289-039 O Ring 1
40 2289-040 Screw 2
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.
