EXPLODED VIEW & PARTS LISTEXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 40401 2.0Ah Battery 1
2 40410-002 Right Handle 1
3 40410-003 Left Handle 1
4 40410-004 Left Housing 1
7 40410-007 Right Housing 1
10 40410-010 Left Air Inlet 1
11 40410-011 Right Air Inlet 1
12 40410-012 Battery Latch 1
13 40410-013 Spring 1
14 40410-014 Switch 1
15 40410-015 Spring 1
16 40410-016 Reset Spring 1
17 40410-017 Spring Support 1
18 40410-018 Electrical Components 1
19 40410-019 Speed Control 1
20 40410-020 Button 2
21 40410-021 Screw 10
22 40410-022 Fan Assembly 1
23 40410-023 Diffusion Assembly 1
22.1 40410-022.1 Plug 1
22.2 40410-022.2 Hex Nuts with Flange 1
22.3 40410-022.3 Washer 1
22.4 40410-022.4 Fan 1
22.5 40410-022.5 Screw 4
22.6 40410-022.6 Gear 1
22.7 40410-022.7 Brushless Motor 1
22.8 40410-022.8 Rectifier 1
22.9 40410-022.9 Screw 3
23.1 40410-023.1 Diffusion Tube 1
23.2 40410-023.2 Damper Screen 1
23.3 40410-023.3 Insulator 2
24 40410-024 Blow Tube 1
25 40410-025 Nozzle 1
26 40410-026 Heat Shrink Tube 1
27 40400C Charger 1
