EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 JN8504-001 Bearing Ring 1
2 JN8504-002 Bearing 607Z 1
3 JN8504-003 Armature 1
4 JN8504-004 Circlip 2
5 JN8504-005 Screw M5x8 2
6 JN8504-006 Bearing 6000Z 2
7 JN8504-007 Spindle Lock Button 1
8 JN8504-008 Spring 1
9 JN8504-009 Gear box 1
10 JN8504-010 Screw ST4.2x22 4
11 JN8504-011 Circlip 1
12 JN8504-012 Column bearing 1
13 JN8504-013 Spring washer 1
14 JN8504-014 Gear 1
15 JN8504-015 Screw M4x8 3
16 JN8504-016 Front cap 1
17 JN8504-017 Small Spring Washer 6
18 JN8504-018 Screw M4x14 4
19 JN8504-019 Woodruff Key 1
20 JN8504-020 Spindle 1
21 JN8504-021 Left Handle Housing 1
22 JN8504-022 Right Handle Housing 1
23 JN8504-023 Cord clamp 1
24 JN8504-024 Screw ST4.2x13 4
26 JN8504-026 Switch 1
27 JN8504-027 Screw ST4.2x16 5
28 JN8504-028 Power Cord 1
29 JN8504-029 Cord Stress Relief 1
30 JN8504-030 Right Brush Cap 1
31 JN8504-031 Left Brush Cap 1
32 JN8504-032 Brush Coil Spring 1
33 JN8504-033 Label 2
34 JN8504-034 Screw ST3.5x10 4
35 JN8504-035 Carbon Brush 2
36 JN8504-036 Brush holder 2
37 JN8504-037 Roller 1
38 JN8504-038 Motor Housing 1
39 JN8504-039 Stator 1
40 JN8504-040 Fan guide 1
No. Part No. Description Qty.
41 JN8504-041 Screw ST4x58 2
42 JN8504-042 Screw M8x12 2
43 JN8504-043 Front handle 1
44 JN8504-044 Pinion 1
45 JN8504-045 Spring washer 1
46 JN8504-046 Nut M8 1
47 JN8504-047 Screw M4x45 1
48 JN8504-048 Depth Stop Nut M4 1
49 JN8504-049 Screw M4x8 2
50 JN8504-050 Depth Stop Block 1
51 JN8504-051 Inner Flange 1
52 JN8504-052 Blade 1
53 JN8504-053 Outer Flange 1
54 JN8504-054 Screw M4 1
55 JN8504-055 Spring 1
56 JN8504-056 Steel Ball 1
57 JN8504-057 Depth Adjustment Dial 1
58 JN8504-058 Screw M5x12 1
59 JN8504-059 Spring 2
60 JN8504-060 Slide plate 1
61 JN8504-061 Base plate 1
62 JN8504-062 Screw M4x6 6
63 JN8504-063 Screw M3x6 2
64 JN8504-064 Depth Scale 1
65 JN8504-065 Support Fence 1
66 JN8504-066 Height Adjustment Knob 1
67 JN8504-067 Height Fence 1
68 JN8504-068 Screw 1
69 JN8504-069 Angle pointer M4x14 1
70 JN8504-070 Angle Fence 1
71 JN8504-071 Dowel 2
72 JN8504-072 Angle Scale 1
73 JN8504-073 Fence Cap 2
74 JN8504-074 Screw M4x16 2
75 JN8504-075 Dust Port 1
76 JN8504-076 Dust Bag 1
77 JN8504-077 Dust Bag Tube 1
78 JN8504-078 Spanner Wrench 1
79 JN8504-079 Angle Adjustment Knob 1
