Wen WB4723 User Manual

EXPLODED VIEW & PARTS LIST
UNPACKING
With the help of a friend or trustworthy foe, carefully remove the work bench from the packaging. Make sure to
take out all contents and accessories. Do not discard the packaging until everything is removed. Check the parts list
below to make sure you have all of the parts and accessories. If any part is missing or broken, please contact our
customer service at 1-800-232-1195 (M-F 8-5 CST), or email techsupport@wenproducts.com.
WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Failure
to follow the safety instructions may result in serious personal injury.
No. Part No. Description Qty.
1 WB4723-001 Front Post 2
2 WB4723-002 Back Post 2
3 WB4723-003 Rubber Foot 4
4 WB4723-004 Side Beam 3
4A WB4723-004A
Side Beam with Power
Strip Opening
1
5 WB4723-005 Bottom Beam 2
6 WB4723-006 Top Beam 2
7F WB4723-007F Front Drawer Bracket 1
7B WB4723-007B Back Drawer Bracket 1
8 WB4723-008 Middle Drawer Mount 1
9L WB4723-009L Left Drawer Mount 1
9R WB4723-009R Right Drawer Mount 1
10L WB4723-010L Left Drawer Panel 2
10R WB4723-010R Right Drawer Panel 2
11 WB4723-011 Front Drawer Panel 2
12 WB4723-012 Back Drawer Panel 2
13 WB4723-013 Drawer Bottom 2
14 WB4723-014 Drawer Handle 2
15L WB4723-015L Left Back Upper Post 1
15R WB4723-015R Right Back Upper Post 1
16F WB4723-016F Front Shelf Beam 1
No. Part No. Description Qty.
16B WB4723-016B Back Shelf Beam 1
17L WB4723-017L Left Shelf Beam 1
17R WB4723-017R Right Shelf Beam 1
18 WB4723-018 Pegboard 1
19 WB4723-019 Bench Top 1
20 WB4723-020 Bottom Shelf 1
21 WB4723-021 Top Shelf 1
22 WB4723-022 Power Strip (not shown) 1
23 WB4723-023 Light Fixture (not shown) 1
A WB4723-024
Bolt (M4x10), Washer,
Nut (not shown)
8
B WB4723-025
Bolt (M6x10), Washer,
Nut (not shown)
78
C WB4723-026
Bolt (M6x16), Washer,
Nut (not shown)
13
D WB4723-027
Bolt (M5x25), Washer,
Nut (not shown)
12
E WB4723-028
Screw (ST4x9.5) (not
shown)
4
F WB4723-029 U Bracket (not shown) 2
G WB4723-030
Bolt (M4x16) (not
shown)
2
8

Wen WB4723 Specifications

General

Brand	Wen
Model	WB4723
Category	Tool Storage
Language	English
