Assembly instructions for kit trailers
P.
Part Listing
BOX # 1 - INTERIOR BOX - METAL
504447 FENDER PLATE - 8”/ 12" (504212) 2 2 2 2
504198 TONGUE SUPPORT FOOT 1 1 1 1
504471 STAKE POCKET 8 8 8 8
500259 LEAF SPRING MOUNTING BRACKET 4 4 4 4
500260 LEAF SPRING AXLE MOUNT PLATE 2 2 2 2
504162 5' TONGUE CONNECTION BRACKET 1 1 1 1
504163 LONG COUPLER CHANNEL 1 1 1 1
BOX # 1 TIRE & FENDER (INCLUDES ITEM LIST IN THE THREE BOXES INSIDE THE TIRE BOX)
ITEM# ITEM DESCRIPTION 4’ x 4’ 4’ x 6’ 4’ x 8’ 5’ x 8’
500258 8” FENDER 2 2 2
500841 4.80 X 8 LRC TIRE & WHEEL 2 2 2
504212 12" FENDER 2
500844 4.80 x 12 LRC TIRE ASSEMBLY 2
BOX # 1 - INTERIOR BOX - LIGHTS
500558 WIRE CONNECTOR 2 2 2 2
500513 TAILLIGHT LEFT/DRIVER SIDE 1 1 1 1
500514 TAILLIGHT RIGHT/PASSENGER SIDE 1 1 1 1
500515 AMBER MARKER LIGHT 2 2 2 2
500516 PLASTIC LICENSE BRACKET 1 1 1 1
500512 4 WAY FLAT 20’ WIRE HARNESS 1 1 1 1
BOX # 1 - INTERIOR BOX - HARDWARE (PICTURES ON THE RIGHT IN REAL SCALE FOR REFERENCE)
500814 3/8” U-BOLT 4 4 4 4
501049 3/8” X 3/4” HEX FLANGE BOLT 20 18 26 26
501033 3/8” X 1 1/2” HEX BOLT 10 13 20 20
501036 3/8” X 3/4” CARRIAGE BOLT 8 8 8 8
501031 3/8” HEX FLANGE LOCK NUT 46 46 61 61
501023 3/8” X 2-1/2” HEX BOLT 1 1 1 1
501024 3/8” X 3” HEX BOLT 2 2 2 2
501032 3/8” FLAT WASHER 8 4 4 4
501060 1/2” X 3 1/2” HEX BOLT 2 2 2 2
501056 1/2” LOCKING NUT 2 2 2 2
501065 9/16 UNF X 3” HEX BOLT 4 4 4 4
501066 9/16 UNF LOCKING NUT 4 4 4 4
501091 #10 X 1/2” PHILLIPS #2 SCREW 8 8 8 8
501092 #10 LOCKING NUT 8 8 8 8
501100 5/16 X 1/2” CUTTING SCREW 4 4 4 4
501001 1/2” WHEEL NUT 10 10 10 10
501073 1/4 X 3/4” HEX BOLT 32 32 32 32
501081 1/4 NYLON INSERT LOCKING NUT 32 32 32 32
500805 1 7/8” COUPLER CLASS I 1 1 1 1
500804 SAFETY CHAIN - 3/16 X 4’ (CLASS I) 1 1 1 1
503079 8” CABLE TIE 4 6 4 4
