VS FULL RANGE SERIES
VS-10 • VS-12 • VS-12M • VS-15 • VS-153
The speakers in this series are a full range, high power handling,
high efficiency cabinet designed for professional applications such
as the reproduction and reinforcement of music, musical
instrument, vocal and spoken voice.
VS SUB BASS RANGE SERIES
VS-15 B • VS-18B
SUB WOOFER OPERATION: Where significant extension of low
frequency output of your system is required, the addition of a VS
Series SUB will provide well balanced, high output enhancement
and power to the overall system.
Passive mode:
In the (standard) passive mode, the power amplifier can be
connected to the EVP SUB system through the system’s internal
low pass filters. The VS Full Range Speaker is connected from the
input/output connector panel and receives a full range signal via
the sub cabinet. (See drawing) Alternatively the sub models can be
connected directly to the amp as can the full range cabinets.
Active mode:
For high output and demanding applications the subs can be
powered directly and exclusively from their own amplifier. For the
recommended x-over point of the particular VS Sub Bass cabinet
being used consult the specification table above under
‘OPERATING BAND PASS’. It is possible to operate subwoofers at
higher low pass frequencies than recommended however system
sound quality and integrity are improved by the use of lower
frequencies. Thus higher output levels can be used with human
voice and instrument fundamentals maintained at more natural
balance. If you have a variable low pass on your active crossover,
we recommend experimenting for the ideal frequency for your
application. Take care to re-adjust relative systems levels for any
frequency changes made.
WHARFEDALE PRO VS SERIES
Wharfedale International Limited, IAG House,
Sovereign Court, Ermine Business Park, Huntingdon,
Cambs, PE29 6XU, England
WHARFEDALE website : www.wharfedalepro.com
IAG Professional reserve the right to alter or improve
specifications without notice.
All rights reserved © 2001Wharfedale Pro
IAG Professional is a member of the International Audio Group
Model name VS-10 VS-12 VS-12M VS-15 VS-153 VS-15SB VS-18SB
FREQUENCY RESPONSE 60 - 20k 50 - 20k 60 - 20k 50 - 20k 50 - 20k 50 - 400Hz 45 - 400Hz
SENSITIVITY 1W@1M 94dB 96dB 96dB 96dB 96dB 97dB 97dB
NOMINAL COVERAGE HOZ 60º 60º 60º 60º —
NOMINAL COVERAGE VERT 45º
60º
45º 45º 45º 45º —
—
—
INPUT POWER (watts)
Continuous 70 125 125 150 180 200 220
Music 140 250 250 300 360 400 440
Peak 280 500 500 600 720 800 880
MAX SPL PEAK 117dB 121dB 121dB 123dB 123dB 123dB 124dB
NOMINAL IMPEDANCE 8Ω 8Ω 8Ω 8Ω 8Ω 4Ω 4Ω
DIMENSIONS (mm) H 469 554 405
624
729 578 735
W 293 428 428 463 535 465 541
D 282 335 625 350 393 400 400
SHAPE Trap Trap US mon Trap Trap Rectangle Rectangle
WEIGHT NET 7.25kg
8.5kg 14kg
12.5kg 11.5kg
13kg
16kg 23kg 21.5kg
23.5kg
30kg
32kg
WEIGHT GROSS 17.5kg 25kg
L F DRIVER SIZE (mm/ins) 200/10 250/12 250/12 380/15 380/15 380/15 440/18
1180/41.7 1362/48.1
65/2.5 75/3.0
steel steel
— —
MAGNET WEIGHT (g/oz) 475/16.8 475/16.8 475/16.8 1180/41.7 1180/41.7
COIL SIZE 38/1.5 38/1.5 38/1.5 38/1.5 38/1.5
FRAME MATERIAL steel steel steel steel steel
MID DRIVER SIZE ————6.5”
Magnet size 307g
Coil size 25.5
Frame material steel
H/F SECTION TYPE Electro/Dynamic Electro/Dynamic Electro/Dynamic Electro/Dynamic Electro/Dynamic — —
SYSTEM BOX FREQUENCY 60Hz 50Hz 45Hz 40Hz 40Hz 40Hz 40Hz
PROTECT TYPE Bulb Bulb Bulb Bulb Bulb — —
OPERATING BAND PASS —————60-180Hz 50-160Hz
FINISH/COLOUR Carpet/Black Carpet/Black Carpet/Black Carpet/Black Carpet/Black Carpet/Black Carpet/Black
CONSTRUCTION MATERIALS Particle board Particle board Particle board Particle board Particle boardParticle board
Particle board
HANDLES QTY 2222222
GRILLE Black full Black full Black full Black full Black full Black full Black full
STAND HI MOUNT Yes Yes No Yes Yes — —
STAND BASS BOX —————YesYes
CONNECTORS IN 2 x
1
⁄
4
” jack input 2 x
1
⁄
4
” jack input 2 x
1
⁄
4
” jack input 2 x
1
⁄
4
” jack input 2 x
1
⁄
4
” jack input 2 x
1
⁄
4
” jack input 2 x
1
⁄
4
” jack input
Ring = - on amp
terminal
Tip = + on amp
terminal
1⁄4” Jack Plug
